Double-rail circular guide rail conveyor line

Double-rail circular guide rail conveyor line with rectangular base plate support and chain drive, horizontal installation.

Core Values: Stable Load Capacity Through Internal and External Collaboration, Efficient Space Utilization, and Heavy-Duty Rigid Adaptability

This conveyor line employs a rectangular closed-loop track layout with nested inner and outer tracks, a single carbon steel base plate support, and an industrial-grade chain drive design. It is specifically optimized for horizontal installation and heavy-duty, high-efficiency operation, fundamentally addressing the pain points of single-track conveyors such as low capacity, heavy-duty deformation, and low space utilization. It is suitable for multi-process heavy-duty production needs requiring synchronous or independent flow.

Stable Load Capacity Through Internal and External Collaboration: The nested inner and outer tracks increase the load-bearing surface by 80% compared to single-track conveyors. Combined with the rigid support of the single base plate, deformation resistance is increased by over 50%. This allows for independent or synchronous operation of the inner and outer tracks, adapting to collaborative processes with different cycle times.

Efficient Space Utilization: The rectangular nested inner and outer tracks save 40% of floor space compared to parallel dual-track conveyors, adapting to compact workshop layouts. The inner and outer tracks can transport materials of different specifications separately, reducing redundant material transfer links.

Heavy-duty, low-consumption, and durable: The carbon steel base plate is aged to eliminate internal stress, and the chain is made of hardened alloy steel with excellent tensile strength; the sealed dustproof structure reduces dust intrusion, extends the maintenance cycle to 18 months, and reduces operation and maintenance costs.

Core Perfo

rmance: Heavy-Duty Precision, Collaborative Stability, and Long-Term Adaptability

Integrating the precision of dual-track guidance with the heavy-duty combination of the base plate and chain, its performance meets industrial heavy-duty conveying standards:

Heavy-Duty Precision Positioning: Collaborative guidance with internal and external tracks, repeatability ±0.08mm; chain drive with dual servo drives; independent adjustment of internal and external track running rhythm with no interference error.

Stable Load-Bearing Operation: Single-station load capacity 100-250kg; rigid connection between the base plate and track; operating vibration amplitude ≤0.1mm; suitable for continuous conveying of heavy-duty materials without deformation.

Multi-Environment Adaptability: The chain is resistant to dust and oil; the base plate surface is sandblasted for rust prevention; stable operation in industrial environments from -10℃ to 60℃ without additional protective devices.

Leveraging the advantages of dual-track operation (internal and external) and the heavy-duty support characteristics of the base plate, it is suitable for multi-process flow scenarios involving heavy-duty materials in various industries.

Specifications and Installation Flexibility: Meets personalized needs

• Track Specifications: Two sizes available (23mm/25mm/44mm/76mm/Custom)

• Installation Methods: Supports horizontal or vertical ceiling mounting

• System Integration: Can be integrated into existing systems without completely replacing the production line

• Drive Compatibility: Compatible with various motors or other drive solutions

• Track Shape: Available in round/elliptical/rectangular/custom shapes

• Length and Layout: Wide range of system sizes, unlimited length, and customizable layout to meet specific customer needs

• Special Versions: Corrosion-resistant versions available for scenarios requiring rust/corrosion resistance (e.g., humid, chemical environments)
