The working principle of the rack guide is to convert rotational motion into linear motion through the meshing of the gear and the rack. When the gear rotates, the teeth on the gear interact with the teeth on the rack, pushing the rack to move linearly along the guide. The movement accuracy and speed of the rack guide depend on the accuracy and speed of the gear, as well as the quality and installation accuracy of the guide.
INQUIRE NOW
Please leave your email address, our professionals will contact you as soon as possible!
PRODUCT DETAILS
Transmission method: rack
Positioning accuracy: ±0.05mm
Dust and dirt proof performance
Load: High
Advantages:
High precision: The rack guide has high-precision straightness and flatness, which can achieve precise linear motion. At the same time, the meshing accuracy of the rack and gear is also high, which can ensure the smoothness and accuracy of the movement.
High load capacity: The rack guide can withstand large loads and impact forces, and is suitable for heavy loads and high-speed movement occasions.
Long life: The rack guide adopts high-strength materials and precise processing technology, and has a long service life. At the same time, the lubrication and maintenance of the guide are also convenient, which can extend the service life of the guide.
Application scenarios:
Machine tool industry: Rack guides are widely used in various machine tool equipment, such as milling machines, lathes, drilling machines, etc. It can realize the linear feed motion of the tool and improve the processing accuracy and efficiency.
Automated production line: In the automated production line, the rack guide can be used to transport materials, position workpieces, etc. It can achieve high-speed and high-precision linear motion to meet the needs of automated production.
Robotics: The rack guide can be used as a linear motion component of the robot to realize the robot's grasping, handling and other operations. It can improve the robot's motion accuracy and stability and expand the robot's working range.
RELATED PRODUCTS
RELATED FAQ
Q: What types of circular guides are available?
According to their shape, they can be divided into elliptical circular guides, circular circular guides, rectangular guides, etc.;
According to the transmission method, they can be divided into synchronous belt circular guides and chain circular guides
Q: What is the accuracy of circular guides?
The repeat positioning accuracy can reach ±0.05mm, depending on the design and manufacturing process of the guide and the quality of the selected components and other factors
Q: How harsh a production environment can it adapt to?
IP65 protection level is optional, supporting a temperature range of -20℃ to 80℃, and an accordion cover is required for dust and humid environments.
Q: Customization and compatibility?
According to the specific requirements of customers, such as guide shape, size, load capacity, accuracy requirements, transmission method, etc., customized circular guide systems are provided for customers
Third-party compatibility: Supports seamless docking with ABB, KUKA robotic arms and Keyence, Cognex vision systems, and provides standardized communication protocols.
Q: Is the circular guide conveyor line adaptable to industry?
Automobile manufacturing, electronics industry, pharmaceutical packaging, daily chemical products, aerospace technology, new energy batteries, scientific research monitoring, etc.
